Great reduction of job changeover
Plate cylinder and
blanket cylinder employ our patent-pending metal-sleeve structure. This makes
format-changes much easier compared with conventional cassette system, and thus
contributes to the reduction of job changeover times.
Low energy consumption
By using energy-efficient LED-UV,
power consumption during printing is cut by around 70% compared with that of
conventional UV dryer.
Film-capability
LED-UV generates very low-level heat
upon drying, so it is possible to print heat-sensitive substrates including
unsupported films. This advantage provides label converters with an opportunity
to participate in flexible packaging market.
Low environmental burden
LED-UV is a very
environmentally friendly solution because it does not use mercury and lamp
lifetime is much longer than conventional UV. Furthermore there is no emission
of ozone upon drying.
Superior print quality
Compared with flexo or
letterpress, offset offers much higher print quality but with much lower plate
cost. Being superior in dot reproduction and half-tone expression, offset adds
further value to printed products.
Combination printing
capability
In addition to offset printing units, a variety of
value-adding units such as varnishing, laminating, foil-stamping as well as
processing units like perforating and punching are available to be added on a
single press.?
| Max. Paper Width | 350mm |
|---|---|
| Max. Printing Width | 330mm |
| Print Repeat Length | 381mm (15”) ~ 609.6mm (24”) |
| Max. Roll Diameter | 600mm |
| Max. Running Speed | 100m/min |
| Material Thickness | 60μm ~ 250μm |
