Variable-data printing
Fully variable printing system, which prints each page with different image and information, creates new value-added products which open up wider business possibilities.
High-quality printing
High-resolution 1200 x 1200dpi printhead with variable droplet control enables more precise dot reproduction and rich tonal gradation, meeting the high-level demand from users who do not compromise on print quality.
Shorter makeready and less inventory
Reduced labor cost and inventory cost generate profitable business conditionsquality.
Wider applications
Full-color printing of up to 6c/6c (CMYK + special 2 colors) surpasses print quality of existing inkjet printers, thus supporting wider range of printing including graphic-arts applications.
Space-saving design
Thanks to Miyakoshi’s original web pass design, a single tower can handle A3 duplex print, consequently making machine footprint much smaller.
Low running cost
Ink-cost is minimized by using water-based dye ink as standard. On the other hand water-based pigment ink is also usable in order to flexibly meet different needs from customers.
Highly accurate paper transport
Miyakoshi’s paper-transport technology that comes from long-year experience in business-form press manufacturing enables stable and accurate printing.
| Printing method | Piezoelectric drop on demand system line head |
|---|---|
| Max. Printing width | 508mm |
| Max. paper width | 520.7mm |
| Resolution | 1200dpi x 1200dpi |
| Number of color | 6c/4c ~ 6c/8c (CMYK + Special 2 colors) |
| Printing speed | 1200dpi x 1200dpi 80m/min 1200dpi x 960dpi 100m/min 1200dpi x 600dpi 160m/min |
| Drop control | 1bit (Binary) · 2bit (Gradation) |
| Usable ink | Water-based pigment ink (specialized for MJP printer) Water-based dye ink (specialized for MJP printer) |
| Drying system | Hot air roll dry system |
